model |
Number of slots |
Shaft hole |
Inner hole |
80×3B level |
3 |
10-28mm |
32mm |
90×3B level |
3 |
10-32mm |
38mm |
100×3B level |
3 |
10-38mm |
45mm |
110×3B level |
3 |
10-38mm |
48mm |
120×3B level |
3 |
13-48mm |
55mm |
130×3B level |
3 |
15-48mm |
customizable |
140×3B level |
3 |
15-48mm |
customizable |
150×3B level |
3 |
16-55mm |
customizable |
160×3B level |
3 |
16-60mm |
customizable |
180×3B level |
3 |
24-65mm |
customizable |
200×3B level |
3 |
24-65mm |
customizable |
220×3B level |
3 |
24-65mm |
customizable |
250×3B level |
3 |
24-65mm |
customizable |
280×3B level |
3 |
28-65mm |
customizable |
300×3B level |
3 |
28-65mm |
customizable |
Note: Tolerance of outer diameter: 3-3mm, support non-calibration.
